BSS BLU-806DA | Soundweb London processor m/4xDSP m. Dante

The Soundweb London BLU-BIB or “break-in box” offers 8 channels of analog audio input expansion via the Soundweb London high bandwidth, fault tolerant digital audio bus. This expander features a low latency, fault tolerant digital audio bus of 256 channels which uses standard Category 5e cabling giving a distance of 100m between compatible devices. The BSS Audio MC-1 fiber optic media converter can be used to increase the distance between devices to over 10km (6.2 miles) using single mode fiber. The BLU-BIB input channels are easily configured by six DIP switches located on the rear of the device, which select consecutive channels in groups of eight. This simple configuration allows assignment to any 8-channel range within the 256 channels available on the digital audio bus. Input channel assignments are configured by DIP switch selection only. The BLU-BIB is not configured by HiQnet™ Audio Architect. Each channel’s input gain and Phantom Power are adjusted using buttons on the front panel. The 8 analog mic/line level inputs utilize the same terminal block connectors as the other members of the Soundweb London family. Signal present, clip, and Phantom Power per channel are displayed by front panel LED indicators. The front panel also contains a power status and applied gain LED indicators. The BLU-BIB operates in three different modes, which are entered and exited via the front panel controls. Edit Mode allows the user to adjust each channel’s input gain and Phantom Power. Normal Mode prevents the user from changing input gain or Phantom Power. Stealth Mode prevents the same changes from occurring, but without LED illumination (except power). The chassis is a half rack wide and can be rack mounted using the BSS Audio 1U Rack-Mount Kit. It can also be under-table mounted or wall mounted using the included mounting brackets. The BLU-BIB break-in box input expander is powered by a 12V DC adapter which is included with the device. The BLU-BIB and the other members of the Soundweb London family provide the building blocks of the perfectly tailored system solution.

The Soundweb London Analog Input Card is designed to populate any of the four card slots on Soundweb London BLU-800, BLU-805, BLU-806, BLU-320, BLU-325, BLU-326, BLU-160, BLU-120, BLU-80, BLU-32 and BLU-16 devices. This analog card enables Soundweb London devices to receive microphone / line level signals. The Soundweb London Analog Input Card offers Phantom Power, configurable per channel and software controlled analog gain in 6dB steps from 0dB to 48dB.

The Soundweb London Analog Output Card is designed to populate any of the four card slots on Soundweb London BLU-800, BLU-805, BLU-806, BLU-320, BLU-325, BLU-326, BLU-160, BLU-120, BLU-80, BLU-32 and BLU-16 devices. This analog card enables Soundweb London devices to send line level signals.

Crown's patenterede DriveCore teknologi gør, at forstærkerne er ekstrem driftssikre og lyder fantastisk. Crown CDien kan kontrolleres, konfigureres og monitoreres via standard TCP/IP netværk vha. HARMAN's HiQnet Audio Architect software. DSP - Crown CDi har fuld DSP og gør det muligt at konfigurere flg.: Input Router Delay - op til 1000ms 8-Band input parametrisk EQ Crossover 8-band Output parametrisk EQ Output Delay - op til 100ms LevelMAX? LimiterBLU link (BL modellerne) Modellerne med BLU Link kan distribuere op til 256 digitale audio kanaler over BLU link via CAT5. Vidste du, at du kan trække op til 100m CAT5 kabel mellem mikser og forstærker! 70/100V el. lav ohm - Hver output kanal kan drives i enten 70V / 100V eller i lav ohm og kan drives i både 2-4-8 ohm GPIO/AUX Port - Forstærkeren er forsynet med GPIO/AUX Port som gør det muligt at genkalde presets, mute kanaler, fejlvisning, samt tænd/sluk funktion af forstærkeren.

The 2x2 Dante is a network audio interface allowing users to integrate up to 2x2 audio channels of Dante audio into networked AV systems. Each input features a microphone preamplifier and 48V phantom power option. The 2x2 Dante features PoE power capability and local power. A small form factor and included mounting ears makes it easy to add Dante connectivity wherever it is needed. It can be close to the audio source or sink to eliminate the need for costly and interference-prone analog wiring.
