Four-channel, 125W @ 4Ω Power Amplifier (EU Version)
Tilgængelighed: Loading...
Tilgængelighed: Sidste på lager
Septons varenummer: 741-02110
Leverandør varenummer: DCI2X2400N-U-EKFX
EAN: 691991009594
DriveCore's front-end drive circuits leverage the inherent efficiency of Class D output stages while also maintaining superb sonic characteristics. The end result is an audio amplifier circuit that exhibits the exemplary audio quality of a highly evolved Class AB design. Powering this remarkable amplifier is the pioneering technology of DriveCore™, which integrates the amplifier drive stage into the power output stage fusing everything into a chip the size of a dime.
Features
- Flexible Input Routing
- Convection Cooled
- Universal Power Supply
- Integrated Life-Safety Features
- Up to 8X125W in 1U chassis with no fan
- DriveCore™ technology provides >90% efficiency with no compromise in performance
- Patented Feedback and Protection Circuits
- Amplifier is stable for 2 – 16 Ohm Loads
- XFMR 4/8 needed for 70V/100V Applications
Specifikationer
| Frequency Response ( 8 Ohms, 20 Hz - 20 kHz) | +/- 0.25 dB |
| BLU Link Input Signal to Noise Ratio (A-Weighted) | > 108dB |
| Total Harmonic Distortion (at full rated power, 20 Hz - 20 kHz) | 0.35% |
| Voltage Gain | 34 dB |
| Damping Factor (20 Hz to 100 Hz) | >5000 |
| Input Impedance (nominal balanced, unbalanced) | 10 kOhms, 5 kOhms |
| Maximum Input Level before Compression | +20 dBu |
| Load Impedance (Stereo/Dual Mode) | 2 - 16 Ohms; 70Vrms and 100Vrms |
| Load Impedance Bridge Mono | 4 - 16 Ohms; 140Vrms and 200Vrms |
| Cooling | Continuously variable speed forced air, front to back airflow |
| Required AC Mains (+/- 10%) | 100V-240V ~ 50/60 Hz |
| IEC Power Connector | 20A IEC |
| Dimensions | 19" x 3.5" x 19" (48.3cm x 8.9cm x 48.3cm) |
| Weight | 24lbs (10.9kg) |
